DMM862 (DD862)Mechanical Energy Meter

	DMM862 (DD862) Single-phase Two-wire Mechanical Active Energy Meter
DMM862-01	Single-phase Two-wire Mechanical Active Energy Meter ( Plastic Cover, Bakelite Base)
DMM862-02	Single-phase Two-wire Mechanical Active Energy Meter (Transparent Plastic Cover, Metallic Base)
DMM862-03	Single-phase Two-wire Mechanical Active Energy Meter (Black Plastic Cover, Metallic Base)
DMM862-04	Single-phase Two-wire Mechanical Active Energy Meter (PC Window, Bakelite Casing )
DMM862-05	Single-phase Two-wire Mechanical Active Energy Meter (Glass Cover, Extended Terminal Cover,Metallic Base)
DMM862-06-R	Single-phase Two-wire Mechanical Active Energy Meter (Round, Transparent Plastic Cover, Bakelite Base)

Main features
1. Compared with DMM28 meter andDMM862 meter DMM862 (DD862) series mechanical energy meter has bigger size, and itis more accurate and steady.
2. Itscover is made of glass, plasticor transparent PC which is anti- UV byoverall molding. A cover made of bakelite with glass window isoptional. Meter base is made of aluminium, steel andbakelite etc. Meter terminal block is made of bakelite whichis moisture resistant and fire retardant byhigh temperature molding.
3. Generally, this mechanical energymeter is equipped with 5 1 digits cyclometer or 5 digit displayer.An uni-directional cyclometercan also be selected.
4. Jewel bearingor magnetic trust bearing are all available.
5. Its frame is made of aluminium alloy by molding with excellent mechanical strength.So it has stable structure.
6. Voltage components and current components ofthis mechanical energy meter allhave good electrical characteristics.
7. Standard configuration adoptsshort terminal covet toreduce installation space and make the installationmore convenient. An extended terminal cover may also beselected to ensure a safe electricity use.
8. Single component measures single phase two wire active energy consumption.It complies with standard IEC62053-11.
9. It adopts direct connect operationand two types of wiring.

Application
DMM862(DD862) single phase two wire mechanical energy meter.
This mechanicalenergy meter is used to measure 50Hz or 60Hz active energy consumption from single phase two wire AC electricity net.
It is widely used in office buildings, shopping mallsand residences, etc.

Technical specification

Type	Accuracy	Rated voltage (V)	Rated current (A)	Overload capacity	Starting current	Insulation performance
DMM862	2.0	220V, 230V, 240V	1.5(6), 2.5(10), 5(20)10(40), 15(60), 20(80), 30(100), etc.	400%Ib	0.5%Ib	AC Voltage 2kV for 1minute, 1.2/50 μs waveform impulse voltage 6kV

HUABANG is a mechanical energy meter manufacturerin China. We offer DIN-rail energymeter, electronic energy meter, mechanical energy meter and socket energymeter, etc. We supply high quality energy meter with competitive price. Ourcompany is based in China where there is full chain for manufacturing energy meter even in one city. Lowmanufacturing cost saves your purchasing cost. More details of each product areshown in specific product page.
